Battery Type

LiFePO4

Nominal Battery Energy

5.12 kWh

Operating voltage

44.8 ~ 57.6V

Nominal Voltage

51.2V

Nominal Capacity

100Ah

Max. output power

3.84kW

Recommended C Rate

0.5C

Recommended Charge/Discharge Current

50A

Recommended Depth of Discharge (DOD)

90%

Net Weight

55 kg

Dimension[W*D*H]

574*228*600 mm

Charging Temp. Range

0~55?

Discharging Temp. Range

-20~55?

Communication

CAN/RS485/RS232

Cycle Life[1]

=6000 Cycles

Protection Level

IP65

Expansion

up to 5 units in parallel

Color

White

Alarms

Overcharge/Over-discharge/Overcurrent/ Overtemperature/Short Circuit

Monitoring & Protection

Each system has smart BMS, breaker embedded in system

Pros

Can be used in both off-grid and hybrid setups, compact design, floor or wall-mounted

Certification & Safety Standard

UN38.3/CE-EMC/IEC62619/IEC62040/IEC60730/GOST-R/UKCA/CEC Accredited
