| Battery Type |
LiFePO4 |
| Nominal Battery Energy |
2.4 kWh |
| Nominal Capacity |
50Ah |
| Nominal Voltage |
48V |
| Operating Voltage |
42 ~ 54.75V |
| Recommended C Rate |
0.5C |
| Recommended Charge/Discharge Current |
25A |
| Max. Power Charge/Discharge Current |
50A |
| Peak Power Charge/Discharge Current |
55A (Protect) |
| Depth of Discharge (DOD) |
90% |
| Net Weight |
22 kg |
| Dimension[W*D*H] |
480*405*90 mm |
| Charging Temp. Range |
0~55? |
| Discharging Temp. Range |
-20~55? |
| Communication |
CAN/RS485 |
| Cycle Life[1] |
=6000 Cycles |
| Protection Level |
lP20 |
| Expansion |
Up to 40 units in parallel |
| Pros |
Can be used in both off-grid and hybrid setups, compact design |
| Certification & Safety Standard |
UN38.3/CE-EMC/IEC62619/IEC62040/CEC Accredited/CEI-021/UL1973/REACH/ROHS/UKCA/GOST-R |
