| Model |
SUN-M130G4-EU-Q0 |
SUN-M160G4-EU-Q0 |
SUN-M180G4-EU-Q0 |
SUN-M200G4-EU-Q0 |
| PV String Input Data |
|
| Max. PV Input Power(W) |
210-460(4 Pieces) |
210-560(4 Pieces) |
210-630(4 Pieces) |
210-700(4 Pieces) |
| Max. PV Input Voltage(V) |
60 |
| Start-up Voltage(V) |
20 |
| MPPT voltage range(V) |
25-55 |
| Rated PV Input voltage(V) |
42.5 |
| Max. Operating PV Input Current (A) |
15+15+15+15 |
| Max. Input Short Circuit Current (A) |
22.5+22.5+22.5+22.5 |
| No. of MPP Trackers/No. of String per MPP Tracker |
4/1 |
|
AC Output Side |
|
| Rated AC Output Active Power(W) |
1300 |
1600 |
1800 |
2000 |
| Max.AC Output Apparent Power(VA) |
1300 |
1600 |
1800 |
2000 |
| Rated AC output current (A) |
6/5.7 |
7.3/7 |
8.2/7.9 |
9.1/8.7 |
| Max.AC Output Current(A) |
6/5.7 |
7.3/7 |
8.2/7.9 |
9.1/8.7 |
| Rated output voltage/range (V) |
220/230 0.85Un-1.1Un |
| Grid Connection Form |
L/N/PE |
| Rated Output Grid Frequency/range(Hz) |
50/45-55, 60/55-65 |
| Max. unit per branch |
5 |
4 |
3 |
3 |
| Power Factor Adjustment Range |
0.9 leading to 0.9 lagging |
| Total Current Harmonic Distortion THDi |
<3% |
| DC Injection Current |
<0.5%ln |
| Efficiency |
|
